Elco 103 Class PT Boat Armor
Elco PT Boat 103 Class Armor

Updates

2012 November 17, page added.


The following images show dimensions for the Elco 80' PT boat bridge armor, in particular for an early 103 class. These dimensional images represent a best effort on my part, please confirm dimensions given here for yourself if errors cannot be tolerated. Images are for non-commercial personal use only, please obtain permission for any other use.


Elco PT Boat 103 Class Armor Dimensions

Elco PT Boat 103 Class Armor Perspective

Elco PT Boat 103 Class Armor Perspective


Reference Images

Elco PT Boat 103 Class John F Kennedy
